Influence of image pixel resolution on canopy cover estimation in poplar plantations from field, aerial and satellite optical imagery


Abstract


Accurate estimates of canopy cover (CC) are central for a wide range of forestry studies. As direct measurements are impractical, indirect optical methods have often been used to estimate CC from the complement of gap fraction measurements obtained with restricted-view sensors. In this short note we evaluated the influence of the image pixel resolution (ground sampling distance; GSD) on CC estimation in poplar plantations obtained from field (cover photography; GSD < 1 cm), unmanned aerial (UAV; GSD <10 cm) and satellite (Sentinel-2; GSD = 10 m) imagery. The trial was conducted in poplar tree plantations in Northern Italy, with varying age and canopy cover. Results indicated that the coarser resolution available from satellite data is suitable to obtain estimates of canopy cover, as compared with field measurements obtained from cover photography; therefore, S2 isrecommended for larger scale monitoring and routine assessment of canopy cover in poplar plantations. The higher resolution of UAV compared with Sentinel-2 allows finer assessment of canopy structure, which could also be used for calibrating metrics obtained from coarser-scale remote sensing products, avoiding the need of ground measurements.


Keywords

foliage cover; crown cover; canopy photography; unmanned aerial vehicles; Sentinel-2

Full Text:

PDF


DOI: http://dx.doi.org/10.12899/asr-2074

References


Angelini A., Corona P., Chianucci F., Portoghesi L. 2015 - Structural attributes of stand overstory and light under the canopy. Annals of Silvicultural Research 39: 23-31. Doi: 10.12899/ASR-993

Chianucci F. 2016 - A note on estimating canopy cover from digital cover and hemispherical photography. Silva Fennica 50(1): 1-10.

Chianucci F. 2020 - An overview of in situ digital canopy photography in forestry.Canadian Journal of Forest Research 50(3): 227-242. doi: 10.1139/cjfr-2019-0055.

Chianucci F.,Disperati L., Guzzi D., Bianchini D., Nardino V., Lastri C., Rindinella A., Corona P. 2016 - Estimation of canopy attributes in beech forests using true colour digital images from a small fixed-wing UAV.International Journal of Applied EarthObservation and Geoinformation 47:60-68.

Chianucci F., Zou J., Leng P., Zhuang Y., Ferrara C. 2019 - A new method to estimate clumping index integrating gap fraction averaging with the analysis of gap size distribution. Canadian Journal of Forest Research 49(5): 471-479.

Chianucci F., Puletti N., Grotti M., Ferrara C., Giorcelli A., Coaloa D., Tattoni C. 2020 - Non-destructive tree stem and crown volume allometry in poplar plantations derived from terrestrial laser scanning. Forest Science (submitted). doi:10.1093/forsci/fxaa021

Coffin D. 2011 - DCRAW: Decoding raw digital photos in Linux.

Eriksson H.M., Eklundh L., Kuusk A., Nilson T. 2006 - Impact of understory vegetation on forest canopy reflectance and remotely sensed LAI estimates. Remote Sensing of Environment 103(4): 408-418.

Grotti M., Calders K., Origo N., Puletti N., Alivernini A., Ferrara C., Chianucci F. 2020 - An intensity, image-based method to estimate gap fraction, canopy openness and effective leaf area index from phase-shift terrestrial laser scanning. Agricultural and Forest Meteorology 280: 107766.

Jennings S.B., Brown N.D., Sheil D. 1999 - Assessing forest canopies and understorey illumination: canopy closure, canopy cover and other measures. Forestry: An International Journal of Forest Research 72(1): 59-74.

Kodar A., Lang M., Arumäe T., Eenmäe A., Nilson, T. 2011 - Leaf area index mapping with airborne lidar, satellite images and ground measurements in Järvselja VALERI test site. Forestry Studies/MetsanduslikudUurimused 55: 11-32.

Korhonen L., Packalen P., Rautiainen M. 2017 - Comparison of Sentinel-2 and Landsat 8 in the estimation of boreal forest canopy cover and leaf area index. Remote sensing of environment 195: 259-274.

Legendre P., Oksanen M.J. 2018 - Package ‘lmodel2’.

Macfarlane C. 2011 - Classification method of mixed pixels does not affect canopy metrics from digital images of forest overstorey. Agricultural and Forest Meteorology 151: 833-840.

Macfarlane C., Grigg A., Evangelista C. 2007 - Estimating forest leaf area using cover and fullframe fisheye photography: thinking inside the circle. Agricultural and Forest Meteorology 146(1-2): 1-12.

Macfarlane C., Ryu Y., Ogden G.N., Sonnentag O. 2014 - Digital canopy photography: Exposed and in the raw. Agricultural and Forest Meteorology 197: 244-253.

Nilson T.1999 - Inversion of gap frequency data in forest stands. Agricultural and Forest Meteorology 98: 437-448.

Nilson T.,Kuusk A. 2004 - Improved algorithm for estimating canopy indices from gap fraction data in forest canopies.Agricultural and Forest Meteorology 124: 157-169.

Paletto A., Tosi V. 2009 - Forest canopy cover and canopy closure: comparison of assessment techniques. European Journal of Forest Research 128(3): 265-272.

Pekin B., Macfarlane C. 2009 - Measurement of crown cover and leaf area index using digital cover photography and its application to remote sensing. Remote Sensing 1(4): 1298-1320.

Prospatin P., Panferov O. 2013 - Retrieval of remotely sensed LAI using Landsat ETM+ data and ground measurements of solar radiation and vegetation structure: Implication of leaf angle. International Journal of Applied Earth Observation and Geoinformation 25: 38-46.

Puletti N., Chianucci F., Castaldi C. 2017 - Use of Sentinel-2 for forest classification in Mediterranean environments.Annals of Silvicultural Research 42: 32-38.

Rautiainen M., Stenberg P., Nilson T. 2005 - Estimating canopy cover in Scots pine stands. Silva Fennica 39: 137-142.

Seed E.D., King D.J. 2003 - Shadow brightness and shadow fraction relations with effective leaf area index: importance of canopy closure and view angle in mixed wood boreal forest. Canadian Journal of Remote Sensing 29: 324-335.
